TCM-HS60ONV/P 60W Onvif Horn IP Speaker
Description
The Network Horn Speaker is a simple-to-install outdoor loudspeaker that provides clear, long-range speech for remote speaking in public notification applications. In emergency, TCM-H60ONV enables an operator to remotely address people and deliver pre-recorded alarm messages which can be manually or automatically triggered via LAN.
Features
- Network 10/100M, RJ45
- Protocol TCP/IP, UDP, HTTP, RTP, ARP, SIP, ONVIF, Multicast
- Power Output 60Watt Class D internal power
- Audio Codec G.711a/u, G.722, G729
- Frequency response 300Hz-17kHz
- Max SPL (1w/1m) 130dB ± 3 dB
- Power Supply 24Vdc / PoE 802.3at
- Material ABS, steel bracket
- Operating Temperature -30°C ~ 65°C
- Environment indoor or outdoor Ip67
Spesification
Specification:
| Model | TCM-HS60ONV/P |
|---|---|
| Network | 10/100Mbps Tx,Rj45 Conector |
| Protocol System | TCP/IP, UDP, HTTP, RTP, ARP, SIP, ONVIF, Multicast |
| Audio Codec | G.711a/u, G.722, G.729 |
| Audio Format | MP3, WMA, WAV |
| Sampling rate | 8K~48KHz |
| Audio bit rate | 8Kbps~320Kbps |
| Rated Power | 60 Watt with Class D internal Power |
| Frequecy response | 300Hz-17kHz |
| Power Source | DC 24V or PoE++ 802.3bt |
| Max SPL (1w/1m) | 130dB ± 3 dB |
| Operation Temperature | -30°C ~ 65°C |
| Material | ABS, steel bracket |
| Environment | Indoor or outdor use with protection IP67 |
| Gross Weight | Approx 3,9kg |
| Dimension | 440mm x 400mm x 200mm |
