TCM-EX15Y/P 15W / TCM-EX30Y/P 30W Atex Horn IP Speaker

Description :

The Techma explosion proof horn speaker is Network IP Speaker model, uses a special explosion-proof material cast shell with good airtightness and a waterproof rating of ip66, which can be used outdoors. In environments with dangerous gases such as oil and natural gas, intrinsically safe explosion-proof speakers can be used with confidence. We are a professional industrial communications solution provider. We develop and manufacture various communication equipment and paging system equipment. Products are widely used in petroleum, metallurgy, chemical industry, sea oil, nuclear power, shipbuilding, tunnels and other projects requiring explosionproof grade speakers. The speaker has passed Atex certification, which is safe and reliable and can be purchased with confidence. This speaker is an active speaker, inside it is a class D power amplifier installed. Easy Remote operation, configuration, operation & monitoring.

Features

  • Network 100BASE-TX,RJ-45 Connector
  • Protocol TCP/IP,Multicast,SIP,RTP,IGMP.
  • Audio codec G.711a/u,G.722,G.729
  • Audio Decoding source MP3,WAV,WMA
  • RJ-45 Connector digital data audio input
  • Built-in of Class D amplifier Industrial grade.
  • Speaker output 15W/30W.
  • Power DC 24V or 802.3bt PoE.
  • Protection Ip66, Atex Ex d e IIC T6 Gb
  • Installation for indoor or Outdoor.
Download PDF Video Solution
Spesification

Specification:

\

ModelTCM-EX15Y/PTCM-EX30Y/P
Rated Power15W30W
Network100BASE-TX, Auto MDI/MDI-X, RJ-45 connector
Network ProtocolTCP/IP, UDP, Multicast, SIP, RTP, RTCP, ARP, ICMP, IGMP
Audio CodecG.711u,G.711a, G.722, G.729
Audio Decoding FormatMP3,WMA,WAV
Audio bit rate8 ~ 320Kbps
Frequency Respone100Hz~10KHz (±3dB)90Hz~20KHz (±3dB)
Sound Pressure Level120dB ±3dB @1mtrs128dB ±3dB @1mtrs
Amplifier Rated Output15W Class D30W Class D
Power Source24VDC / PoE 30W24VDC / PoE 60W
Broadcasting ModeMulticast & SIP Broadcasting Mode
Dispersion angle H:110°
Dust/Water ProtectionIP66
Operating Temperature-30°C to +65°C
Operating Humidity90 % RH or less (no condensation)
Ex CertificateATEX Ex d e IIC T6 Gb
FinishABS, Antistatic Polymade, Stailess steel bracket
ColorBlack
DimensionsØ250x352mmØ250x352mm
Weight3,7Kg4Kg
OptionBracket,Midspan PoE 30WBracket,Midspan PoE 90W
